Geospatial Analysis from 30 Minutes to Seconds

The Six Feet Up engineering team treated the POC as validated research, not as a codebase to incrementally improve. The R/Shiny implementation had proven the algorithms worked. The remaining challenge was delivering them predictably.

Choosing the Right Foundation

Every technology choice was driven by a specific production requirement: horizontal scaling, spatial query performance, artifact storage, and infrastructure repeatability.

The application was rebuilt on a Python/Django backend with a React frontend, deployed on Kubernetes. PostgreSQL with PostGIS extensions handled spatial queries. Raster datasets moved to AWS S3 storage. Terraform managed infrastructure-as-code to eliminate environment drift between deployments.

Testing the Data Access Bottleneck

The biggest unknown was how to handle multi-gigabyte raster datasets without introducing latency spikes or dependencies on external services.

Three strategies were tested against real production data:

• External API calls to a geospatial provider at request time
• Complete local preprocessing of all raster data
• Hybrid preprocessing with selective caching

Testing revealed the hybrid approach was most reliable. Rasters were preprocessed and stored in S3, then cached locally using Kubernetes persistent volumes. This eliminated repeated downloads while reducing dependency on external services during live requests.

With data access stabilized, the next bottleneck became clear: too much data was being processed per request.

Scoping the Request to the Problem

The fix was architectural. Instead of loading entire regional rasters and filtering down, the pipeline was redesigned to extract only the raster windows intersecting the user's drawn boundary (think of a polygon drawn on an interactive map). Request runtime now scaled with field size, not dataset size.

That change moved 20–30 minute workflows into an interactive range. Some completed in seconds.

Moving Expensive Computation Off the Critical Path

Speed alone wasn't sufficient. The system also needed to be predictable under load.

Geospatial clustering (identifying zones with similar characteristics) was removed from the live request path entirely. Clusters were pre-calculated and versioned as static files loaded at startup. When clustering parameters changed, a batch job regenerated the files. The complexity was still there. It just wasn't happening during a user's request.

Modeling Constraints from the Start

The recommendation engine was rebuilt using a linear programming model (PuLP) that evaluated availability alongside optimality. When a preferred option was out of stock, the system returned feasible alternatives rather than failing or ignoring the constraint. This shifted the tool from an academic exercise into something a frontline user could act on.

The re-architecture made the system production-ready. What had been a 20–30 minute workflow became interactive. What had been unpredictable became reliable.

Three architectural principles drove the improvement:

• Minimize data read per request
• Move expensive computation out of the request path
• Incorporate real-world constraints into the model from the start, not as an afterthought

The results confirmed that the underlying science could work at production scale, but only with an architecture designed for it.

If you're scaling a POC into a production system: test data access patterns with real datasets early. Measure where time is actually spent. Lock in your approach to data before building features on top of it. Experimentation beats assumptions.
